Continuously Reinforced Concrete Pavement (CRCP) type rigid concrete pavement in the form of high-strength precast panels made in a precast factory, each panel reinforced with prestressed cables. Between panels are connected with special dowels that are more flexible called dowel activators so that they can function to distribute (dissipate) the vehicle load to the body of the panel.
| Product ID | BC-2.3-0.15 |
| Availability | Prepared by Order |
| Price | Please contact our marketing |
| Width (mm) | 2000 |
| Height (mm) | 150 |
| Length (mm) | 3000 |
| Thickness (mm) | 150 |
| Volume (m3) | |
| Weight (kg) | 2160 |
| Moment Crack (ton.m) | |
| Moment Ultimate (ton.m) | |
| Allowable Axial Load (Ton) | |
| Crack Load (kN/m) | |
| Ultimate Load (kN/m) | |
| Outer Diameter (mm) | |
| Inner Diameter (mm) | |
| Hydrostatic Pressure (MPa) |
Kali Baru
| Owner | PT Waskita Karya (Persero) Tbk |
| Nilai Proyek | 1,996,072,800 |
| Project Year |
| ITEM | SPECIFICATION | REFERENCE | |
| Aggregate | ASTM C33 – 2016 | (Standard Specification Concrete Aggregates) | |
| SNI 8321-2016 | (Concrete Aggregate Specification) | ||
| Cement | SNI 15-2049-2004 | (Portland�s Cement) | |
| Admixture | ASTM C494 – 2016 | (Standard Specification for Chemical Admixture for Concrete) | |
| Concrete | Compressive Strength at : 28 Days : 350 kg/cm2(Cube) ; 30 Mpa (Cylinder) | SNI 2847-2013 | (Structural Concrete Requirement) |
| Reinforced Rebar | BjTS 40 For D ? 13mm | SNI 2052-2014 | (Concrete Reinforcement Steel Bar) |
| BjTP 24 For D < 13mm | SNI 2052-2014 | (Concrete Reinforcement Steel Bar) | |
